100W LED Flood Light Description
GS LIGHT 100w led flood light unique multi-point compression type integrated waterproof patent structure, 100% gule free structure, IP66.
High conductivity aluminum radiator, ventilation and convection design. The lamp body is miniaturized and the power is large. SUS304 stainless steel screw bracket is equipped with a dial and has the function of gear locking.
The lamp body adopts a unique design concept, with smooth arc, simple and natural shape. The self leveling design of the lamp surface ensures that there is no deposition of foreign matters on the surface, avoid the later maintenance and cleaning of the lamp.
Equipped with Cree/Osram/Philips high-power light source, it has excellent light and color performance. Temperature resistant, high transparent,flame-retardant optical lens, with built-in anti glare column technology, minimize glare and stray light, optional with built-in bee net anti glare grid.
High conductivity aluminum radiator, ventilation and convection design. The lamp body is miniaturized and the power is large. SUS304 stainless steel screw bracket is equipped with a dial and has the function of gear locking.
The lamp body adopts a unique design concept, with smooth arc, simple and natural shape. The self leveling design of the lamp surface ensures that there is no deposition of foreign matters on the surface, avoid the later maintenance and cleaning of the lamp.
Equipped with Cree/Osram/Philips high-power light source, it has excellent light and color performance. Temperature resistant, high transparent,flame-retardant optical lens, with built-in anti glare column technology, minimize glare and stray light, optional with built-in bee net anti glare grid.
100W LED Flood Light Beam Angle
The beam angle represents the angle at which the luminaire distributes light. Depending on your environment, you might want a wider or more narrow beam angle.
Generally, LED flood lights provide a wide beam angle in order to light up larger outdoor areas well, but for some high buiding Decoration you need narrow beam angle to light up a long distance.
Generally, LED flood lights provide a wide beam angle in order to light up larger outdoor areas well, but for some high buiding Decoration you need narrow beam angle to light up a long distance.
Outdoor Flood Lights Dimension
Led Garden Light Specification
Model No.
GSL-N60
GSL-N100
GSL-N150
GSL-N200
GSL-N240
GSL-N300
Power
60W
100W
1500W
200W
240W
300W
Material
Die casting aluminum
Light efficiency
140 lm/w
Beam Angle
TYPE ||, TYPE III
Voltage
AC100–277V; 108-305V
LEDs
Philips Lumileds 3030
Dimming
DALI / 1-10V / PWM / FIVE LEVELS DIMMING
Driver
Philips / Meanwell
PF
>0.95
LED Lifespan
108000H (at 25°C ambient temperature)
IP
IP66
Impact Resistance
IK08
CRI
>80
CCT
3000K / 4000K / 5000K / 5700K
Working Temp
-30°C ~ +55°C
Options
Photocell / Surge protection device / External cable
Color
Grey / Black / White
Dimensions (mm)
580x240x149mm
580x240x149mm
740x344x149mm
740x344x149mm
840x400x149mm
840x400x149mm
Warranty
5 Years
LED Billboard Light Applications
Park, lawn, bridges, courtyards, advertising light, building decoration and landscape lighting etc…
