LED Sports Lighting Description
The GS RG series is a high-performance LED Sports Lighting specifically designed for top-tier sports events and harsh outdoor environments. It integrates ultra-high luminous efficacy, superior protection, and intelligent control. Made of anti-corrosion aluminum alloy and featuring multiple protection technologies, it achieves a luminous efficacy of up to 170lm/W. It is equipped with a 10kV lightning protection module (SPD), offering IP67 water resistance and IK10 impact resistance. It supports multi-angle light distribution and full-protocol dimming, meeting the lighting requirements of professional venues, high-definition broadcasting, and smart city management.
LED Sports Lighting Triple Protection
LED Sports Lighting Triple protection against lightning strike, dust and water, and impact: Built-in 10kA (20kV) surge protection device (SPD) effectively guards against lightning damage; IP67 grade fully dustproof and waterproof, suitable for long-term immersion; IK10 grade impact-resistant casing withstands 10 joules of impact, suitable for extreme environments such as ports and mining areas.
High protection,reliable performance
IP67 protection level, unafraid of rain, snow, dust and corrosive environments; pure aluminum heat sink ensures efficient heat dissipation, ensuring the lamp maintains stable output even in high-temperature conditions, with a lifespan of up to 50,000 hours.
High Light Efficiency Up To 170lm/W
Adopting advanced SMD 3535/5050 chips and optical system, it achieves a super high luminous efficacy of 170lm/W, saving over 80% energy compared with traditional lamps and significantly reducing long-term operating costs.
Datasheet Of LED Sports Lighting
Model No.
GS-RG-500W
GS-RG-600W
GS-RG-1000W
GS-RG-1200W
GS-RG-1500W
Power
500w
600w
1000W
1200W
1500W
Materials
Die casting aluminum+PC
Light efficiency
160/170 lm/W
Input Voltage
100 - 277Vac /180-528Vac (50/60Hz)
Beam angle
8°/12°/ 22°/40°/60°
PF
>0.97
LED Lifespan
>50000 hours
IP
IP67
Impact resistance
IK08
Working temperature
-30°℃- +55℃
CRI
>70/80
CCT
3000K/4000K/5000K/5700K/6500K
LxWxH(mm)
408x420x238
408x420x238
536x539x476
536x539x476
595x615x510
Warranty
5 Years
Beam Angle LED Sports Lighting
The LED Sports Lighting SH series offers four high-power models ranging from 500W to 2000W, forming a complete high-power product matrix.
It aims to provide the most precise and efficient lighting solutions for various outdoor lighting projects, from small areas to national-level large venues.
It aims to provide the most precise and efficient lighting solutions for various outdoor lighting projects, from small areas to national-level large venues.
LED Sports Lighting Sizes
LED Sports Lighting RG series offers a comprehensive selection of five power models—from 500W to 1500W—each engineered with optimized dimensions to deliver tailored lighting solutions for projects of all scales.
GS-RG-500W, GS-RG-600W
GS-RG-1000W, GS-RG-1200W
GS-RG-1500W
Applications In Different Scenarios
500W - 600W: Suitable for tennis courts, basketball courts, and medium-sized training grounds
1000W - 1200W: Suitable for standard football fields, rugby fields and regional stadiums
1500W: Large main stadium, venue for international events, airport apron
1000W - 1200W: Suitable for standard football fields, rugby fields and regional stadiums
1500W: Large main stadium, venue for international events, airport apron
LED Sports Lighting FAQs
LED Stadium Lights provide uniform illumination that reduces shadows and improves visibility for both players and maintenance staff in high-risk areas.
Beam angles from 8° to 60° allow precise control of light coverage for different field sizes and pole heights.
Lower energy usage and reduced maintenance frequency significantly decrease total lifecycle costs.
Efficient thermal management prevents LED degradation and maintains stable lumen output over time.
Directional beam control limits stray light, improving environmental lighting efficiency.
It enables centralized smart control of multiple lighting zones in large venues.
